Vulcan Heat Drying System by Omnitec

This unit holds 11 KW industrial strength heating elements with a variable speed blower and precision auto temperature control. It operates on 208/230 V from 30 amp dryer outlet, or 50 amp stove outlet and is compatible with 50 amp Spider boxes. The unit can also be hardwired into an electrical panel and hold compact housing with non-marking casters and two rubber coated handles make for an easy grip. It can be easily placed and set up where heat is needed most without long ducting or any loss of heat. When ducting is necessary, the flex duct can be connected to the outlet and the inlet sides quite easily. The heater is compact and easy to store while being lightweight enough for one person to use.

Features:

• Vulcan 11 KW heater delivers 19,000 or 37,000 BTU on 30 or 50 amp service with precise temperature and airflow control.
• Temperature controller with digital display can regulate temperature up to 160° F.
• Included is 25’ long sensor to monitor remote containment air or material temperature.
• The airflow can be set between 100 to 475 CFM by turning a dial.
• 6 Heating elements can be individually turned ON, providing great system flexibility.
• Temperature rise is about 15° F per heating element (90° F total).
• 10” outlet and inlet have flex duct connections.
• Safety features include temperature safety switch with 180° F cutoff and air flow switch.
• The heater elements are in double-walled, insulated compartment to keep the housing just warm even when under full load.
• Safe to operate in horizontal or vertical position.
• Vulcan can be handled by a single person as it is compact and light.
